Pressure Sensors
Fuji Electric's pressure sensors combine piezo resistance, adjustment circuits, and EMC protection on a single chip and contribute to the reduction of system size. They can be used over a wide pressure range and can be applied to various applications.
Features
-
Absolute pressure measurement
-
High-precision guaranteed by digital trimming
-
Compatible with a wide range of pressure ranges, with a full scale of 100 kPa - 300 kPa
-
Overvoltage protection circuit, electromagnetic wave cutoff circuit, and surge protection circuit built into a sensor chip
-
Equipped with a diagnostic self-detection function for disconnects in Vcc, Vout, and GND wiring
-
Ensures high reliability by EPROM redundancy
| Model type | Maximum applied pressure (kPa.abs) |
Allowable voltage (V) |
Operating temperature (ºC) |
Operating pressure (kPa.abs) |
Operating voltage (V) |
Output voltage range (V) |
Absolute pressure Relative pressure |
Package |
|---|---|---|---|---|---|---|---|---|
| EPL4PC-R3S | 500 | 7 | -40 to 125 | 20 to 106.7 | 5.0±0.25 | 0.789 to 4.211 | Absolute pressure |  Exterior |
